JK-5C1500 Gravure Press for Wall Paper Printing, PVC Film Printing
Keywords:
Jinkun
Category:
Description
Application examples
|
Floor Covering |
Printed PVC Table Cover |
|
Table Cover Printing |
Wallpaper |
Large volume high speed tablecloth coloring
The JK-5C1500 5-color gravure press has a printing width up to 1500mm. The gravure printing machine performs at high production speeds of up to 150m/minute, making it a popular choice for multiple colors printing on large scale prints.
Specifications
Plate cylinder: shaftless
Tension range: 5-50kg
Tension precision: ±5kg
Maximum pressing force: 1500kg
Drying method: electrical heating (optional conduction oil heating)
Weight: 30T
Applicable ink: oily ink, water-based ink
Applicable printing materials: flexible packaging films, such as PVC, OPP, CPP, PET, Nylon, PE and paper
Main configuration
- 1 shaftless duplex unwinder
- 1 preheating unit
- 3 printing cylinder and drying system
- 1 tension control system
- 1 rewinding unit
Customization
- Not only do we provide standard configuration gravure presses, but we also offer customization services to process materials with special widths and colors.
- Printing width : 1-4.2m.
- Print color: 1-12.
- All electrical configurations can be adjusted according to your requirements.
