JK-3C1500 Flexographic Printing Machine
Keywords:
Jinkun
Category:
Description
Application Example
|
Plastic Tablecloth |
Printed Floor Paper |
|
Wallpaper Printing |
Wallpaper Printing |
Ideal Equipment for Wide Format Printing
JK-3C1500 is a three-color gravure printing machine, capable of printing materials with a width of 1500 mm.
JK-3C1500 is suitable for printing various soft packaging films such as PVC, OPP, CPP, PET, Nylon, etc., especially suitable for printing PVC decorative materials.
Due to the different properties of materials, the printing tension and speed also vary.
The maximum printing speed of JK-3C1500 is 110 m/min, with a tension range of 5-50 kg. You can adjust the printing speed and tension according to the characteristics of different materials to ensure excellent printing quality.
Parameters
Tension Range: 5-50kg
Tension Accuracy: ±5kg
Maximum Imprinting Force: 1500kg
Drying Method: Electric Heating (optional thermal oil heating)
Equipment Weight: 30T
Applicable Inks: Oil-based Ink, Water-based Ink
Applicable Printing Materials: Soft packaging films, such as PVC, OPP, CPP, PET, Nylon or PE, paper
Main Configuration
- 1 Set of Dual Station Center Unwinding
- 1 Set of Preheating Calender Roll
- 3 Printing Units (Printing + Drying)
- 1 Set of Traction Unit, 1 Set of Rewinding Unit
Custom Options
- We not only provide fixed configuration gravure printing machines, but we can also offer customized services based on the width and color of the materials you want to print.
- The printing width we can customize is: 1-4.2 meters
- The number of colors we can customize is: 1-12 colors
- All electrical configurations of the equipment can be customized according to your requirements.
