JK-4C1600 Gravure Press for Bopp Film Printing, PET Film Printing
Keywords:
Jinkun
Category:
Description
Application examples
|
Printed Paper |
PVC Wallpaper |
|
PVC Printed Wallpaper |
Table Cloth |
JK-4C1600 Gravure Press for Bopp Film Printing, PET Film Printing is specially designed for printing on flexible packaging films made of PVC, OPP, CPP, PET, Nylon, etc. The gravure printing machine features a maximum speed up to 150 m/min and tension range of 5-50 kg. The tension and speed vary depending on the different materials, which can be adjusted according to the different material properties to achieve excellent print quality.
Specifications
Tension range: 5-50kg
Tension precision: ±5kg
Maximum pressing force: 1500kg
Drying method: electrical heating (optional conduction oil heating)
Weight: 35T
Applicable ink: oily ink, water-based ink
Applicable printing materials: flexible packaging films, such as PVC, OPP, CPP, PET, Nylon, PE and paper
Main configuration
- 1 shaftless duplex unwinder group
- 1 preheating unit
- 4 printing cylinder and drying system
- 1 tension control system
- 1 rewinding unit.
Customization
- Not only do we provide standard configuration gravure presses, but we also offer customization services to process materials with special widths and colors.
- Printing width : 1-4.2m.
- Print color: 1-12.
- All electrical configurations can be adjusted according to your requirements.
